Features

    * TCAS control used in conjunction with transponder control to provide ARINC 429 control of TDR-94D transponder and TCAS II System
    * Accepts mode A and mode C code from CTL-92, parallel code from CTL-90 or ARINC 429 code from compatible ARINC 429 controls
    * Adds TCAS control data to mode A and mode C code and outputs data via ARINC 429 output words for appropriate transponder
    * Models available with black or gray bezel (see table below)
    * Models available with 5 or 28 volt lighting (see table below)
    * Models available with variations of OFF-STBY-AUTO-TA ONLY switch selections (see table below)
    * Models available with variations of display control pushbuttons (see table below)
    * Models available with additional range selections for 40 and 3 nmi (see table below)

Specifications

    * Weight: 1.3 lbs.
    * Dimensions: 2.395"W x 2.645"H x 6.83"L
    * TSO: C112, C119
    * EUROCAE: ED-14B (Env), ED-12A (software)
    * Input Power: 28VDC (16 to 32) at 7W max
    * Lighting: 5V ac/dc blue-white lighting at 350Ma 28V dc blue-white lighting at 100Ma
